fireworks-tech-graph

fireworks-tech-graph is an open-source agent skill that turns plain English or Chinese descriptions into polished, geometry-checked technical diagrams — outputting SVG, high-resolution PNG, and validated animated GIFs. It runs unchanged inside both OpenAI Codex and Anthropic Claude Code, and is published under the MIT license. The project reached v1.2.0 with a verified semantic SVG-to-GIF motion runtime shared across all twelve visual styles.

What It Is

fireworks-tech-graph is a diagram-generation skill for AI coding agents. Instead of writing Mermaid DSL or clicking through draw.io, a developer describes a system in natural language — "Draw a Mem0 memory architecture, dark style" — and the skill classifies the diagram type, generates a geometry-safe SVG, exports a 1920px PNG, and optionally produces an animated GIF with draw-on connector animation and persistent data flow. The skill ships with 12 distinct visual styles, 14 UML diagram types, and built-in pattern knowledge for AI/Agent architectures including RAG, Agentic RAG, Mem0, Multi-Agent, and Tool Call flows.

How the Skill Works

The generation pipeline follows a bounded, agent-driven validation loop rather than treating the first render as final:

• Natural language in — trigger phrases like "draw a diagram", "visualize", "architecture diagram", or Chinese equivalents (画图 / 帮我画) auto-classify the diagram type and style.
• Semantic IR — typed nodes and edges are normalized to a versioned schema; duplicate IDs, dangling references, and malformed waypoints fail before rendering.
• Geometry-safe routing — deterministic orthogonal routes, exact waypoints, distinct port fan-out, label and legend avoidance, and verified bridge jumps keep wires out of boxes.
• Structured SVG validation — XML and marker integrity, semantic node checks, reserved-region, canvas, edge-overlap, and edge-crossing checks run before export.
• PNG visual readback — exported PNGs are inspected for clipping, overlap, label placement, and routing regressions before delivery.
• Targeted correction — each pass changes only diagnosed coordinates or spacing, then reruns validation; at most two focused correction passes are allowed by default.

Twelve Visual Styles and Motion

Styles 1–7 and 9–12 are deterministic generator-backed profiles; Style 8 (Dark Luxury) is AI-authored with a static regression fixture. Every style shares one approved motion contract: connectors begin absent, draw in on frames 1–36, fade to live flow on frames 36–38, hold full settled flow on frames 38–109, and reset on frames 110–114 — producing a 5.75-second, 20fps, 115-frame infinite loop at 960px wide. Style highlights include:

• Flat Icon (default) — white background, colored accents, suited for blogs and slides
• Dark Terminal — dark background, monospace fonts, ideal for GitHub READMEs
• Blueprint — engineering grid, cyan lines, for architecture docs
• Glassmorphism — frosted glass cards on dark gradient, for product sites and keynotes
• C4 Review Canvas — enforces one declared C4 abstraction level with responsibilities and protocols
• Ops Pulse — golden signals, one critical path, OTel export, and a correlated trace

AI/Agent Domain Patterns and Shape Vocabulary

The skill encodes semantic meaning into shapes consistently across all styles: LLMs use double-border rounded rectangles, Agents use hexagons, Vector Stores use ringed cylinders, and Queues use horizontal pipes. Arrow stroke and dash patterns encode flow type — solid for primary data flow, dashed for memory writes, and curved for feedback loops. Built-in pattern knowledge covers RAG Pipeline, Agentic RAG, Agentic Search, Mem0 Memory Layer, Agent Memory Types, Multi-Agent, and Tool Call Flow. Over 40 brand icons ship as inline SVG with correct brand colors — covering OpenAI, Anthropic, Pinecone, Weaviate, Kafka, LangChain, LangGraph, CrewAI, Kubernetes, and Grafana, among others.

Update: v1.2.0 — Semantic SVG→GIF Motion Live

Version 1.2.0, published July 2026, is the current release. The headline change is a unified, fail-closed SVG-to-GIF motion runtime applied to all twelve styles. The runtime validates draw-on sequence, settled data flow, the 5.75-second timeline, frame cadence, and infinite looping before atomically installing the final GIF artifact. The project reports 9,587 GitHub stars and 802 forks as of the last metadata update.

Setup Path

Install via the skills CLI into Codex and Claude Code simultaneously:

npx -y skills@1.5.17 add yizhiyanhua-ai/fireworks-tech-graph/skills/fireworks-tech-graph --agent codex claude-code -g -y --copy

Alternatively, clone the repository directly into ~/.agents/skills/ for Codex or ~/.claude/skills/ for Claude Code. PNG export requires cairosvg (recommended) or rsvg-convert; animated GIF export additionally requires FFmpeg, Chrome/Chromium, and Puppeteer. Python 3.9+ is required; the optional Puppeteer path requires Node.js 18+.
